NOTE:
Intel 13th & 14th gen CPUs may require a BIOS update
Digi Power
Unlike traditional motherboards that use analog power, this motherboard uses a next generation digital PWM (Pulse-Width Modulation) design, which provides CPU Vcore voltage more efficiently and smoothly, so that the stability and lifespan of the motherboard is greatly enhanced.
Ultra M.2 32Gb/s (PCIe Gen3 x4)
The PCIe Gen3 x4 Ultra M.2 interface pushes data transfer speeds up to 32Gb/s.
Auto Driver Installer
No need to worry about lack of disk drive! Asrock preinstall LAN driver to ensure that you are able to install all drivers needed in an easier way than using SCD.
step1: Install Auto Driver Installer
step2: Update drivers needed
step3: Done!
Dual HDMI Outputs
Equipped with two of the most widely used HDMI connectors, enjoy better multi-monitor compatibility and an easy setup experience.
HDMI 4k @60Hz
Supports the most recent HDMI 4K 60Hz graphics output specification. With the larger bandwidth and increased frame rate, the motion on your screen becomes more fluid and less blurry.
| Weight | 0.71 kg |
|---|---|
| Brand | |
| MPN | |
| EAN |
SPECIFICATION
Motherboard Type: Desktop
Form Factor: mATX
Socket: Intel 1700
Chipset: Intel H610
CPU Support: Supports 14th, 13th & 12th Gen Intel Core Processors (LGA1700)
RAM Technology: DDR5 (Dual Channel)
Supports Intel XMP 3.0
RAM Slots: 2 x DIMM
RAM Speeds: Up to 5600 MHz
Maximum Memory: 128GB
Graphics: Integrated Graphics*
*Graphics specifications may vary between CPU types
Graphics Ports:
2 x HDMI 2.1
Multi-GPU Support: N/A
PCI/PCI Express:
1 x PCIe 4.0 x16 (supports x16 mode)
1 x PCIe 3.0 x1
Storage:
4 x SATA III
1 x M.2 (2242/2260/2280) – PCIe 3.0 x4
RAID: N/A
Wireless: N/A
LAN: GB LAN
Audio: N/A
USB Ports Supported:
Rear:
2 x USB 3.2 Gen1 Type-A
4 x USB 2.0
Front:
2 x USB 3.2 Gen1 Type-A
2 x USB 2.0
Back Panel I/O Ports:
1 x PS/2 Mouse/Keyboard
2 x HDMI
2 x USB 3.2 Gen1 Type-A
4 x USB 2.0
1 x RJ-45 LAN
HD Audio Jacks
Internal I/O Connectors:
1 x SPI TPM
1 x Chassis Intrusion and Speaker
1 x CPU Fan
1 x Chassis/Water Pump Fan
1 x 24 pin ATX
1 x 8 pin 12V
1 x Front Panel Audio
1 x USB 2.0
1 x USB 3.2 Gen1
Accessories:
1 x User Manual
1 x I/O Shield
2 x SATA Data Cables
1 x Screw for M.2 Socket
Package Type: Retail
